冷凝切片机安装操作与注意事项
发布时间:2021-10-06 14:47:47 来源:http://www.chinafoodjx.com 发布人:admin

一般情况下通过切片机成型的原料,相比其他粉碎型加工的原料,更能提高产品的档次,同时设备稳定性好,操作方便。所以冷凝切片机在化工,制药等行业被广泛应用。在进行冷凝切片机的操作时一定要遵守操作程序,注意学习安全知识。
Generally, the raw materials formed by slicer can improve the grade of products compared with other crushed raw materials. At the same time, the equipment has good stability and convenient operation. Therefore, condensing slicer is widely used in chemical, pharmaceutical and other industries. When operating the condensing slicer, be sure to follow the operating procedures and pay attention to learning safety knowledge.
冷凝切片机是将加热的液体原料,不锈钢内冷却转辊在设备的料槽内转动粘带至前部的可调节式切片刀装置对其进行切片,从而使液体经冷却刀片转换为固体片料,亦可对液体经冷却变为结晶体的原料进行切片。
The condensing slicer is an adjustable slicer device that rotates the heated liquid raw material and the stainless steel internal cooling rotating roller in the material groove of the equipment to the front for slicing, so as to convert the liquid into solid sheet material through the cooling blade, and also slice the raw material from the liquid into crystal after cooling.
一、安装及操作程序
1、 Installation and operation procedures
1、先检查设备是否损坏,后安装到位。注意保证滚筒的水平位置。
1. First check whether the equipment is damaged, and then install it in place. Pay attention to the horizontal position of the drum.


2、把输送物料的管道与切片机的进口连接好,进料管道上顺装调节阀门。
2. Connect the pipeline conveying materials with the inlet of the slicer, and install the regulating valve on the feed pipeline.
3、把转辊两头水冷却接头按进水和出水接好,热媒加热管与设备连接装好。
3. Connect the water cooling joints at both ends of the rotating roller according to the inlet and outlet, and connect the heat medium heating pipe with the equipment.
4、开机检查运转是否正常,根据电柜指示,先按电源启动按钮,再打开变频器调速有慢道快,观察运转是否正常。然后把切片刀和转辊的间隙调好。
4. Start up and check whether the operation is normal. According to the instructions of the electric cabinet, first press the power start button, and then turn on the frequency converter. The speed regulation is slow and fast, and observe whether the operation is normal. Then adjust the gap between the slicer and the rotating roller.
5、接通冷却水进料刀片,根据切片厚度调节进料的速度,检查切片的厚度及其他要求能否达到要求。切片刀装置顺调至和转辊无间隙。
5. Connect the cooling water feeding blade, adjust the feeding speed according to the slice thickness, and check whether the slice thickness and other requirements can meet the requirements. The slicer device shall be smoothly adjusted to have no gap with the rotating roller.
6、一般正常物料凝固点在50度以上,可采用自来水冷却,若凝固点低,需配置冷冻设备,冷却越快,产量越高。
6. Generally, if the freezing point of normal materials is above 50 ℃, tap water can be used for cooling. If the freezing point is low, refrigeration equipment needs to be configured. The faster the cooling, the higher the output.
二、应注意事项
2、 Precautions
1、切片机电器部分必须进行接地。变频器纯虚比较复杂,请预先阅读变频器说明书,以防程序错乱,造成不能使用。
1. The electrical part of the slicer must be grounded. The frequency converter is complex. Please read the manual of the frequency converter in advance to prevent the program from being disordered and making it unusable.
2、下料盆及下料口的地方属高温区,应避免接触.
2. The place of the blanking basin and the blanking opening belongs to the high temperature area, and contact should be avoided
3、应注意下料盆物料凝固,万一凝固,应关闭电源,把下料盆升温之物料溶解为止,然后方可继续生产。
3. Pay attention to the solidification of the materials in the blanking basin. In case of solidification, turn off the power supply and dissolve the materials heated in the blanking basin until they are dissolved, and then continue production.
4、涡轮减速机在生产之前应先加齿轮油。
4. Gear oil shall be added to the turbine reducer before production.
