菜的尺寸减小:转动可调偏心轮,使槽的开口朝上,松开可调偏心螺丝,向偏心轮中心方向适量移动.
The size of the dish is reduced: the eccentric wheel can be adjusted by rotation, so that the opening of the groove is upward, and the eccentric screw can be loosened, and the eccentric screw can be moved to the center direction of the eccentric wheel.
竖刀用于茎、叶类软菜的切断,以及将离心切片机构切好的片切成所需规格的丝或曲线、块、丁、菱形等花样,切制不同花样的菜需要安装相应的竖刀.
The vertical knife is used to cut off the soft vegetables of the stems and leaves, and to cut the slices of the centrifuge slicing mechanism into the required sizes of silk or curve, block, Ding, rhombus and so on. The cutting of different kinds of dishes requires the installation of the corresponding vertical knife.
产品出厂时,随机安装料筒刀一把,其他规格的刀具(直刀,菱形刀,曲线刀,方块刀),可根据用户的需要定做.
When the product is out of factory, it will be installed at random, and other specifications of the tool (straight knife, diamond knife, curve knife, square knife) can be customized according to the needs of users.
竖刀切菜尺寸可在1-25mm任意调整,通过调整可调偏心螺丝,得到所需的尺寸.
The size of vertical cutting vegetables can be adjusted arbitrarily at 1-25mm, and the required size can be obtained by adjusting the adjustable eccentric screws.
片刀固定在料筒壁上,刀刃与拨料斗盘有0.5-1mm间隙.切片厚度可通过调整活动板两侧螺丝钉得到,调好后紧固螺母.
The blade is fixed on the wall of the material barrel, and the blade has 0.5-1mm clearance with the bucket tray. The thickness of the slice can be obtained by adjusting the screws on both sides of the movable plate, and the nut is adjusted after fastening.
竖刀速度根据切菜尺寸及蔬菜选择,切细丝时选高速,粗丝和切菜尺寸较大时依次选中速和高速.
Vertical knife speed is selected according to the size of cut vegetables and vegetables. When cutting the filaments, choose high speed, coarse wire and cut vegetables are large in size, then select speed and high speed in turn.
三角带张紧:调整机器后方,调整螺杆顺时针旋转即可张紧.切片机构张紧,可调整电机板螺母达到张紧目的.
Tension of the triangle belt: adjust the rear of the machine, adjust the screw to rotate with clockwise rotation. The cutting mechanism is tightened, and the nut of the motor plate can be adjusted to achieve tensioning purpose.
1、长时间不使用切菜机、果蔬清洗机时，请放置在干燥、通风的地方
1. If you don't use vegetable chopper or fruit and vegetable cleaning machine for a long time, please place it in a dry and ventilated place.
2、每次使用过后需及时清洗，确保清洁，确保无食材、物料、的残渣在内
2. Every time after use, it should be cleaned in time to ensure cleanliness and ensure that there is no residue of ingredients, materials and residues.
3、定期给关键零部件、螺丝上油，鉴于此食品机械的特殊性，上油可用高品质的橄榄油进行润滑
3. Regularly lubricate key parts and screws. In view of the particularity of this food machinery, oiling can be lubricated with high quality olive oil.
4、定期检查关键部位，做好维护工作，再好的机械，没有人细心的维护，使用寿命终究是不会长远的。
4, regular inspection of key parts, good maintenance, good machinery, no one careful maintenance, life will not be long after all.
以上便是切丁切块机今天的分享，您还满意吗，欢迎关注我们的网站：http://www.chinafoodjx.com并且关注我们的产品，我们将为您提供优良的产品，衷心的愿与您建立合作关系。
The above is the Chopin cutting machine today's sharing, are you satisfied, welcome to our website: http://www.chinafoodjx.com and pay attention to our products, we will provide you with excellent products, sincerely wish to establish a cooperative relationship with you.
