切片机操作规程是什么?
发布时间:2022-04-28 23:06:54 来源:http://www.chinafoodjx.com 发布人:admin

切片机是切制薄而均匀组织片的机械,在使用切片机前,应检查电源开关是否完整无损,擦拭机器,将载物台移至最右边,漏出加油口,向其中加几滴润滑油,多次横向载物台,使润滑油均匀分布。切片机使用时遇到紧急情况应立即关闭紧急刹车开关。接下来就和小编一起来了解一下切片机使用知识吧。
The slicer is a machine for cutting thin and uniform tissue slices. Before using the slicer, check whether the power switch is intact, wipe the machine, move the stage to the far right, leak the oil filler, add a few drops of lubricating oil to it, and cross the stage several times to make the lubricating oil evenly distributed. In case of emergency when using the slicer, turn off the emergency brake switch immediately. Next, let's learn about the use of slicer with Xiaobian.
一、切片机操作规程
1、 Operating procedures of slicer
(一)开机前准备
(1) Preparation before startup
1、在切片机使用之前,打开副滚筒蒸汽阀门,预热下料盆,避免因物料和筒体之间有凝固层,而不能正常操作,一般保温到物料成液体状态即可。打开冷冻机,水泵及相关阀门使冷却水置换至主滚筒中。
1. Before the slicer is used, open the steam valve of the auxiliary drum and preheat the blanking basin to avoid the failure of normal operation due to the solidification layer between the material and the cylinder. Generally, it can be kept warm until the material becomes liquid. Open the refrigerator, water pump and relevant valves to replace the cooling water into the main drum.
2、在使用切片机前,应检查电源开关是否完整无损,擦拭机器,将载物台移至右边,漏出加油口,向其中加几滴润滑油,多次横向载物台,使润滑油均匀分布。
2. Before using the slicer, check whether the power switch is intact, wipe the machine, move the stage to the right, leak the oil filler, add a few drops of lubricating oil to it, and cross the stage several times to make the lubricating oil evenly distributed.
3、在使用切片机前,应检查刀片上是否有异物,检查刀具护板是否盖实,检查磨刀砂轮是否远离刀片。
3. Before using the slicer, check whether there are foreign matters on the blade, whether the tool guard is covered tightly, and whether the grinding wheel is far away from the blade.
4、在使用切片机前,应调节切割厚度,先将厚度调至大,再调至需要厚度。调好后将夹具打开,放入物料,夹实,并落下重锤。
4. Before using the slicer, the cutting thickness should be adjusted. First adjust the thickness to the maximum, and then adjust it to the required thickness. After adjustment, open the clamp, put in the material, clamp it tightly, and drop the heavy hammer.
(二)切片机开机
(2) Slicer on
1、打开电源开关。
1. Turn on the power switch.
2、用“箱体温度设置按钮”将箱体温度设置到切片机所需温度。
2. Use the "box temperature setting button" to set the box temperature to the temperature required by the slicer.
3、用“样品头温度设置按钮”设置样品头温度。
3. Use the "sample head temperature setting button" to set the sample head temperature.
(三)切片机切片
(3) Slicer slicing
1、安装好刀片,用夹紧样刀旋钮固定刀片,待刀片与箱体温度一致后方能切片。
1. Install the blade, fix the blade with the clamping sample knife knob, and slice the blade after the temperature of the blade is consistent with that of the box.
2、用“切片厚度调节旋钮”调节切片所需的切片厚度。
2. Use the "slice thickness adjustment knob" to adjust the slice thickness required for slicing.


3、将样品放到样品托上,涂敷包埋剂,放到冷台上冷冻。
3. Put the sample on the sample holder, apply the embedding agent, and freeze it on the cold table.
4、将冷却透的样品放到样品头上,夹紧样品托的旋钮。
4. Place the cooled sample on the sample head and clamp the knob of the sample holder.
5、推进刀架使刀接近样品,用样品快进按钮将样品移近刀口。
5. Push the knife edge close to the sample holder with the button.
6、调节防卷板的位置,使切出的样品平整的进入防卷板与刀片的狭缝。
6. Adjust the position of the anti roll plate to make the cut sample enter the slit between the anti roll plate and the blade smoothly.
7、可利用控制面板上的“键盘锁按钮”将键盘锁定。
7. The keyboard can be locked by using the "keyboard lock button" on the control panel.
8、当停机时,应将玻璃窗打开,待机器完全干燥后再开机。
8. When the machine is shut down, open the glass window and start the machine after it is completely dry.
以上就是为大家介绍的有关切丝切片机的详细介绍,希望对您有所帮助.如果您有什么疑问的话,欢迎联系我们.我们将以专业的态度,为您提供服务http://wwwchinafoodjxcom/
The above is the detailed introduction of the slicer. I hope it will be helpful to you If you have any questions, please contact us We will provide you with professional service http://wwwchinafoodjxcom/
